Technical Specifications:
– Dimensions (W x D x H): 90 x 62 x 38mm
– Motor: Electronically commuted ball bearing motor
– Rated voltage: 12V DC
– Power consumption: 18W
– Maximum head pressure: up to 5.2m
– Maximum flow rate: up to 1000L/h
– Maximum liquid temperature: 60°C
– Materials: Stainless steel, PPS-GF40, EPDM O-rings, Aluminium oxide, hard coal
– Power connector: SATA power and 4-Pin PWM FAN connector for PWM / RPM readout
Made in the EU.
PLEASE NOTE:
-
- DDC pumps are wet tested before shipping. While they are dried out before packaging, it can occasionally happen that the pump is deliver still slightly wet.
- This product should NOT be installed with any aluminum Fluid Gaming parts!
- If no PWM signal is present, DDC pump runs at 100% RPM.
Additional Info
| Threads | G1/4 |
|---|
