Technical Specifications:
– Finish: Nickel
– The outer diameter: 16.5mm
– Installed height: 8mm
– Thread: G1/4”, 4.5mm male thread length
– O-ring material: EPDM 50
– Temperature probe type: NTC, 10KΩ at 25°C
– Temperature sensing range: 0°C to 90°C
– Connector: 2-pin
– Cable length: 500mm
ROHS compliant!
Designed and engineered by EK Water Blocks in Slovenia – Europe
Made in China
PLEASE NOTE:
- The use of specifically engineered coolants that contain corrosion, scale, and biological inhibitors is mandatory to prevent damage of the nickel platting. EK offers a selection of such products in the coolants section.
- Avoid using the EK-Loop Connect – Temperature Plug Sensor on ports that are not in contact with the coolant from the custom liquid cooling loop, as this will give inaccurate measurements.
- This product should NOT be installed with any aluminum Fluid Gaming parts!
Additional Info
| Material / Design / Color option | Nickel |
|---|---|
| Threads | G1/4 |
